ClearView HD3111 Single HDMI Input HD ISDBT/DVBT 6M Encoder Modulator


ClearView HD3111 Single HDMI Input HD ISDBT/DVBT 6M Encoder Modulator for Brasil and South America

Out of stock

SKU: hd3111 Categories: ,


This Modulator is for Europe, Australia, New Zealand Brasil and South America
It will modulate in DVBT 6/7/8M and ISDBT 6M.

Please see our Alibaba site for Export Orders

User Manual Here

Latest Firmware here

The HD Encoder Modulator supports 1 HDMI inputs and 1 RF F female output.
An RF carrier can carry one high-definition program at 12 Mb/sec encoding rate.
After encoding and modulating, the input signal can be directly outputted or mixed with
the original TV signal. It can be widely used in home entertainment,
security, protection monitoring, hotel LCD panels, shopping mall advertising etc..

Input: HDMI (Type A) x 1 (The HDMI Input supports HDCP)
Output : ISDBT/DVBT-6MHz modulator (F female)
ISDBT Frequency : 173.143-219.143MHz 473.143~767.143MHz
Adjustable LCN, ONID, NID, TSID, KEY ID and Channel Name.
USB Port for software upgrade.
RF Input and Loop out via F cnnector

Local Interface  control buttons + LCD panel

Input Format: HDMI
Encoding: HDMI: MPEG4 H.264/AVC
Resolution: HDMI: up to 1920x1080_60p , 1920x1080_50p
Connector: HDMI (Type A)

Input Format: HDMI
Encoding Format: ADPCM, MPEG-1 layer 2 audio and AAC-LC streams.
Connector: HDMI embedded audio

ISDBT/DVBT Modulation
Standard: ISDBT (ARIB STD-B31)  DVBT/6M Bandwidth
Bandwidth: ISDBT 6 MHz, DVBT 6/7/8M
Mode: 8K
Code rate:  5/6
Constellation: 64QAM
Guard Interval: 1/32
Frequency Range: 173.143~219.143MHz 473.143~767.143MHz (ISDBT)
                               177 to 803MHz (DVBT/6/7/8MHz)
Output Level: 90 ~ 105dBuV

Power Supply:  Power Pack 100-240VAC 50/60Hz, Output 12 VDC 500mA
Output Level:  90 ~ 105dBuV
Operating Temperature: 0 to +50 degrees C
Storage Temperature: -10 to +70 degrees C
Size, 168 x 118 x 60mm
Weight: 1.0Kg

Additional information

Weight 1.000 kg
