ClearView DTV SMART METER COMBO model CV19811

Description

DVB-S2/T2, ISDB-T REAL-TIME SPECTRUM & TOUCH PANEL

➢ Fast and reliable signal data processing
➢ Patented dual-frequency spectrum scan and capture module
➢ Rich spectrum analysis functions
➢ Specific details of measurement statistics for channel quality
➢ Constellation for digital TV signals
➢ Antenna/LNB angle calculation
➢ Satellite motor DiSEqC and dCSS MDU application support
➢ dCSS MDU support
➢ LNB power compensation
➢ Audible tone to reflect signal strength
➢ High-resolution LCD display & Capacitive touch panel
➢ Friendly and intuitive graphical user interface
➢ High capacity lithium battery for long operation and storage hours
➢ USB interface for firmware upgrade and file transfer

GENERAL
LCD                       3.95′, 480 x 3(RGB) x 320, 16-bit Colour
Touch Panel       Capacitive ScreenActive
Touch Area         55.68mm x 83.52mm
Power Adapter 12VDC / 1A
Battery                 2 Cell / 2500mAh
Power Consumption     8W max.
Dimension (W x D x H) 8.27′ x 3.07′ x 1.06′ (210 x 78 x 27mm)
Interface             USB 2.0 x 1
Function             Firmware Upgrade, Sat/TP and Terrestrial/Cable Channel Plan Modification
|
DTV STANDARDS
DVB     -S ETSI EN 300-421 v1.1.2
DVB-T      ETSI EN 300-744 V1.6.1
DVB-S2      ETSI EN 302-307 v1.4.1
DVB-T2      ETSI EN 302-755 v1.3.1
ISDB-T      ARIB STD-B31 v2.2
